Carbon Guard combines 450 GSM unidirectional carbon fiber, structural epoxy, and a patented top and bottom anchoring system to reinforce appropriate bowing, cracked, tipped, and sheared foundation walls.
Carbon Guard is more than carbon fiber bonded to a wall. It is a complete reinforcement system designed to stabilize appropriate foundation-wall movement and resist further inward deflection.
Unidirectional carbon fiber provides tensile resistance, while structural epoxy saturates the fabric and bonds it to the prepared substrate. The patented top and bottom anchoring system supplements that bond and helps transfer reinforcement loads through the surrounding structure.
Together, these components create a complete reinforcement system built around strength, consistency, and contractor-friendly installation.
Carbon Guard's patented top and bottom anchoring system supplements the bonded carbon fiber and creates a complete reinforcement path across the wall.
Unidirectional carbon fiber concentrates tensile strength in the primary direction needed to resist continued inward wall movement.
The Carbon Guard Shear Plate helps transfer textile loads into the substrate and improve shear resistance near the heavily loaded wall base.
Carbon fiber is well suited for structural reinforcement because it provides high tensile strength while remaining lightweight, low-profile, and resistant to corrosion.
Carbon Guard uses 450 GSM unidirectional carbon fiber, concentrating the fibers in the primary reinforcement direction. When fully saturated with structural epoxy and bonded to a properly prepared wall, the fabric and epoxy work together as a reinforced composite.
The patented anchoring system then supplements the bonded reinforcement at the top and bottom, helping maintain engagement and transfer loads through the complete system.
Contractors choose Carbon Guard because it combines a straightforward installation process with a complete reinforcement system. The carbon fiber, structural epoxy, patented top and bottom anchors, and bottom Shear Plate are designed to work together rather than relying on bonded fabric alone.
The system is designed for appropriate lateral wall movement, including bowing, tipping, and shearing conditions. Defined installation procedures and technical resources help crews deliver consistent results across varying wall types and project conditions.
Carbon Guard combines high-strength carbon fiber with patented mechanical anchoring to create a complete, low-profile wall reinforcement system designed for appropriate foundation stabilization applications.
Have gaps That lead to Continued wall movement & shifting
has unidirectional carbon fiber fabric that limits further movement ensuring safety for years
Carbon Guard follows a straightforward installation sequence designed to help crews work consistently from one project to the next.
The process includes evaluating and laying out strap locations, preparing the substrate, installing top-anchor hardware, applying structural epoxy, placing the carbon fiber, and completing the bottom anchor and Shear Plate assembly.
Clear instructions and purpose-built components help reduce unnecessary complexity while maintaining the preparation, bonding, and anchoring required for system performance.
Whether you’re evaluating Carbon Guard for an upcoming project or looking for product, installation, or distribution information, our team is ready to help.
